OEM / ODM ： Single Cavity Injection Mold & Transparent Router Bottom Housing (1*1) No.23892

Ask Latest Price

Video Channel

Brand Name :Chitwing

Model Number :Router

Certification :ISO 9001:2015

Place of Origin :Vietnam

MOQ :1set

Price :Negotiable

Payment Terms :L/C, T/T

Supply Ability :180 set/month

Delivery Time :30 day(s)

Packaging Details :The mold is packaged with a wooden box and placed on a wood pallet.

Mold Weight :1600kg

Size :580X 600 X 560.2

IMM Tonnage :180T

Mould base :LKM

Design software :3D:UG 4.0, 2D:CAD

Product material :PC+10%GF

more

Contact Now

Add to Cart

Shell (1*1) / Cold runner / Two-plates mold No.19014-B

Shell (1*1) / Cold runner / Two-plates mold No.19014-B

OEM / ODM ： Single Cavity Injection Mold & Router Upper Cover (1*1) No.23891

OEM / ODM ： Single Cavity Injection Mold & Router Upper Cover (1*1) No.23891

OEM / ODM ： Single Cavity Injection Mold & Transparent Router Upper Cover (1*1) No.23891

OEM / ODM ： Single Cavity Injection Mold & Transparent Router Upper Cover (1*1) No.23891

Shell (1*1) / Cold runner / Two-plates mold No.19014

Shell (1*1) / Cold runner / Two-plates mold No.19014

OEM / ODM ： Single Cavity Injection Mold & Router Bottom Housing (1*1) No.23892

OEM / ODM ： Single Cavity Injection Mold & Router Bottom Housing (1*1) No.23892

OEM / ODM ： Single Cavity Injection Mold & Transparent LH Bracket (1*1) No.23399

OEM / ODM ： Single Cavity Injection Mold & Transparent LH Bracket (1*1) No.23399

OEM / ODM ： Single Cavity Injection Mold & LH Bracket (1*1) No.23399

OEM / ODM ： Single Cavity Injection Mold & LH Bracket (1*1) No.23399

OEM / ODM ： Custom Electronic Enclosures & Transparent top cover (1*2) No.23392

OEM / ODM ： Custom Electronic Enclosures & Transparent top cover (1*2) No.23392

OEM / ODM ： Single Cavity Injection Mold & Middle housing (1*1)No.23394

OEM / ODM ： Single Cavity Injection Mold & Middle housing (1*1)No.23394

OEM / ODM ： Single Cavity Injection Mold & Middle housing (1*1) No.23394

OEM / ODM ： Single Cavity Injection Mold & Middle housing (1*1) No.23394

View Product Description

Transparent Router Bottom Housing

No.23892

【Mold base】 - DCI5060 120150120
【Size】 - 580X 600 X 560.2
【Standard】 - LKM
【Gate】- Point gate + side gate

【Type】- Three-plate mold
【Product material】- PC+ABS
【Injection/runner type】- Hot runner

Features
I. Two core slide	II. Four core slanting
III. 10 core tunnel slide	Ⅳ. 19 angular lifters

【Surface treatment】
⑴ Grade I critical surface treated with VDI27# pattern
⑵ Grade I critical surface treated with Charmilles VDI18#

【Material of mold cavity and mold core】
Quenched (1*1/S136)

【Mold net weight】- 1600kg
【Tonnage of forming machine】- 180T

【Product net weight/size】- 74.47g
【Product net weight/size】- 127.00x182.07x59.79mm

Display diagram
